Image is for your reference only,please check specifications for details

LADN02 - Schneider Electric
Manufacturer:
Schneider Electric
ManyChip's Part#:
MC16224517
Category:
Industrial Relay
Datasheet:
Datasheet 3D Model
Description:
"Schneider Electric / Square D LADN02 IEC Auxiliary Contact Block 690V AC At 25 - 400Hz, 10A, 2NC, Front Moun...
Stock Locations:
Availability:
0 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The LADN02 is a 2NC front mounting Auxiliary Contact Block with screw clamp terminals and instantaneous operation. It is compatible with the TeSys D/F CR1F contactors and control relays.
30M Cycles mechanical durability
5mA Minimum switching current
17V Minimum switching voltage
1.5ms Overlap time
>10MR Insulation resistance

Show

LADN02 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Snap-In
Number of Contacts	2 Contact
Supply Voltage (DC)	690 V
Current Rating	10 A
Contacts Type	DPST-NC
Contact Current Rating	10 A
Operating Temperature (Max)	60 ℃
Operating Temperature (Min)	-5 ℃
Supply Voltage	690 V
	Show
Operating Temperature	-5℃ ~ 60℃
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
