RSX101VAM30TR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	SMD-2
Number of Positions	2 Position
Forward Voltage	470mV @1A
Forward Current	1000 mA
Max Forward Surge Current (Ifsm)	5 A
Maximum Forward Voltage (Max)	470 mV
Forward Current (Max)	1000 mA
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Junction Temperature	150℃ (Max)
	Show
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status
ECCN Code	EAR99
