Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Pin Pitch | 2.54 mm |
Number of Contacts | 2 Contact |
Gender | Male |
Contact Plating | Gold |
Voltage Rating (DC) | 250 V |
Current Rating | 3.00 A |
Number of Rows | 01 Row |
Glow Wire Compliant | Non-Compliant |
Halogen Free Status | Not Low Halogen |
Orientation | Vertical |
Number of Circuits | 2 Circuit |
Flammability Rating | UL 94 V-0 |
Number of Positions | 2 Position |
Current Rating (Max) | 3A/触头 |
Maximum Contact Resistance (Max) | 30 mΩ |
Show | |
Size-Length | 7.37 mm |
Size-Width | 6.6 mm |
Size-Height | 11.81 mm |
Housing Color | Black |
Color | Black |
Contact Material | Phosphor Bronze |
Material | Brass |
Housing Material | Thermoplastic |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ELV Compliant | Compliant |
REACH SVHC Compliance | No SVHC |
ECCN Code | EAR99 |
