Description

You will no longer have to worry about under or overvoltages with this voltage detector TC54VC2702ECB713 voltage monitor IC from Microchip Technology. This device has a maximum power dissipation of 240 mW. Its maximum power dissipation is 240 mW. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This voltage supervisor IC has an operating temperature range of -40 °C to 85 °C. It has a typical reset threshold voltage of 2.7 V, with a minimum of 2.65 V and a maximum of 2.75 V. This device has a minimum operating supply voltage of 0.7 V and a maximum of 10 V.

Show

TC54VC2702ECB713 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23-3
Supply Voltage (DC)	700mV (min)
Supply Current	1.00 µA
Number of Positions	3 Position
Power Dissipation	240 W
Quiescent Current	1.10 µA
Threshold Voltage	2.7 V
Reset Threshold Voltage (Min)	2.65 V
Reset Threshold Voltage (Max)	2.75 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	240 mW
Supply Voltage	10 V
Supply Voltage (Max)	6 V
Supply Voltage (Min)	0.7 V
	Show
Size-Length	3.1 mm
Size-Width	1.8 mm
Size-Height	1.3 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
HTS Code	8542390001
ECCN Code	EAR99
